Vertikalfräsmaskin modell FSN 300A mm
TECHNICAL DATA:
Working table size 1000 x 350 mm
Aluminium carriage sliding on hardened and polished guides 1000 x 310 mm
Spindle moulder at 4 speeds 2500-3500-6000-80000 RPM
Diam. of table collars 75-105-140-180-220 mm
Work spindle diameter 30 mm
Spindle tilting -5°+45° degree
Max. diam. of tool above the table 200 / 250 mm
Max. diam. of tool under the table 175 mm
Spindle length 130 mm
Useful spindle length 80 mm
Three-phase motor 400 V, 50 Hz (S6/40%) 3,7 kW
Suction dust hood diam. 100 mm
Net weight 270 Kg
Basic machine includes:
Aluminium sliding table complete with angle fence and steel table
Spindle moulder fence with adjustable extensions
Spindle moulder wooden fences of the wood presser
Emergency stop
Overload protection
CE standards
Service spanners
Instruction handbook
Spindle moulder with lower suction
Spindle lock for 0°, -5°, 45°
