TECHNICAL DATA:
Machine dimensions 4000 x 1300 x 1450 mm
Working table sizes 2500 x 800 mm
Table stroke 420 mm
Lateral stroke 700 mm
Abrasive belt - width x length 6800 x 150 mm
Belt speed 17 m/sec.
Motor 3 x 230/400 V, 50 Hz 3,0 kW
Lifting motor 3 x 230/400 V, 50 Hz 0,2 kW
Suction dust hood diam. 2 x 180 mm
Suction capacity 2 000 m3/h
Speed of suction air 20 m/sec.
Noise level (Lpa) 74 dB (A)
Max. weight of the work piece 100 kg
Weight PBD 2500 420 kg
Basic machine includes:
Electric table control
Service spanners
Instruction handbook
